Premium Quality Sliding Bushing
| Manufacturer | DALON |
| Material | COMPOSITE MULTILAYER |
| Type | FLANGE BUSHING |
| Working Temperature | From -200°C to + 280°C |
| Product Code | DOB-1F |
| Density (g/cmÂł) | 7.5 |
| HS Code | 8483300090 |
| Hardness | >220 |
| Static Load (Mpa) | 250 |
| Max Speed (m/s) | 2.5 |
| Max PV (dry) | 1.8 |
| I.D.(d) | 15 |
| I.D. (d1) | |
| O.D. (D) | 17 |
| O.D. (D1) | |
| Length (L) | 1 |
| Flange Dia. (fd) | 23 |
| Flange Thickness (fl) | 9 |
| General Tolerance | F7 r7 js13 |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty | 40KGS |
DALON’s Sliding Flange Bushing 15×17×23×1×9 is a precision-engineered bronze flange bearing designed for smooth, maintenance-free operation in rotary and linear motion applications. With an integrated flange for axial positioning, this bushing ensures quick installation and consistent alignment in compact assemblies where space is critical.
This model follows DALON’s dimension convention:
Inner Diameter (ID): 15 mm
Outer Diameter (OD): 17 mm
Flange Outer Diameter: 23 mm
Flange Thickness: 1 mm
Total Length: 9 mm
Manufactured using a porous sintered bronze alloy, the structure is impregnated with oil for long-term self-lubrication. The flange eliminates the need for stop rings or shoulders, offering a simpler and more secure axial fixing method.
Size: 15×17×23×1×9 mm (ID × OD × Flange OD × Flange Thickness × Total Length)
Material: Sintered bronze alloy (oilless, graphite-enhanced optional)
Lubrication: Self-lubricating – oil embedded within the porous bronze
Working Temp: –40°C to +250°C
Max Load: Up to 60 N/mm² (dynamic)
Friction Coefficient: Low, suitable for dry-run systems
Installation: Press-fit or slip-fit; flange ensures axial alignment
Industrial control levers
Linear actuator housings
Precision instrumentation and mechatronics
Compact gearboxes or servo mechanisms
Small robotic joints and pivots
Office equipment and miniaturized machinery
As a certified manufacturer under ISO 9001:2015, DALON delivers consistent and customizable bronze bushings tailored to OEM needs. Our flange bushings provide:
Customization Options: Pore size, dimensions, flange styles, lubrication
Quick Delivery:
In-stock molds: 30 days
New custom mold: 35–40 days including design
Advanced Materials: Bronze, graphite-filled bronze, or composite options
Full Engineering Support: Design assistance, performance consulting, and application testing
|
Question |
Answer |
|---|---|
|
Q1: What is a flanged bronze bushing used for? |
It provides axial and radial shaft support in machines requiring compact, precise alignment. |
|
Q2: Does it need lubrication during use? |
No. The sintered structure is pre-impregnated with oil, offering maintenance-free use in most applications. |
|
Q3: Can I request a different size or material? |
Yes. DALON supports full customization including special tolerances, materials, and surface treatments. |
|
Q4: How quickly can custom orders be delivered? |
Custom designs typically ship within 35–40 days, including mold development. Standard mold parts take around 30 days. |
|
Q5: Is this suitable for dry environments or enclosed systems? |
Yes. It’s ideal for sealed housings or dry operation where additional lubrication is not feasible. |
|
Q6: What industries typically use this type of bushing? |
Commonly found in automation, home appliances, robotics, and compact mechanical assemblies. |
The self-lubricating properties of SLIDING FLANGE BUSHING 15X17X23X1X9 make them ideal for numerous applications, including:
SLIDING FLANGE BUSHING 15X17X23X1X9 are designed for environments where traditional lubrication is impractical or impossible. They offer outstanding performance, durability, and cost savings, making them the preferred choice for various industries. Experience the reliability and efficiency of SLIDING FLANGE BUSHING 15X17X23X1X9, tailored to meet the demands of your specific applications.
Our professional team is ready to assist with your inquiry for this Bronze Flanged Bearing 15×17×23×1×9 – Compact & Reliable.
