Premium Quality Sintered Bushing
| I.D.(d) | 10 |
| I.D. (d1) | |
| O.D. (D) | 15 |
| O.D. (D1) | |
| Length (L) | 20 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | F7 r7 js13 |
| Weight(ref)/Gram | 13.00 |
| Minimum Order Qty | 40KGS |
10×15×20 mm sintered bronze plain bearing is a compact and efficient solution for low-friction, maintenance-free shaft support in industrial and mechanical assemblies. Manufactured from porous sintered bronze and pre-impregnated with lubricating oil, this self-lubricating plain bearing ensures consistent performance and long service life without the need for external grease or oil.
Its cylindrical design is ideal for radial load applications and ensures smooth rotation with minimal wear.
Dimensions:
• Inner Diameter (ID): 10 mm
• Outer Diameter (OD): 15 mm
• Length: 20 mm
Material: Sintered bronze (CuSn), oil embedded
Type: Plain cylindrical bearing
Lubrication: Self-lubricating (pre-oiled)
Installation: Press-fit into housings or bearing seats
Performance:
• Quiet, smooth operation
• High wear resistance
• Suitable for dry or semi-dry environments
Small electric motors and fans
Gearboxes and power tools
Automotive linkages
Office machines and household appliances
Industrial automation equipment
DALON is a professional manufacturer of oil-impregnated sintered bronze bushings, trusted by OEMs worldwide. With ISO 9001:2015 certified production and decades of experience in powder metallurgy, we deliver bushings with consistent pore structure, dimensional accuracy, and reliable oil retention.
We support full OEM customization—diameter, length, tolerance, alloy formulation, or packaging—all tailored to your product design.
Q1: What makes this a “plain” bearing?
It has a simple cylindrical shape without flanges or grooves, providing basic support for radial motion.
Q2: Is the bearing pre-lubricated?
Yes. The sintered bronze is vacuum impregnated with oil, enabling self-lubrication during use.
Q3: Can it be used in both static and rotating applications?
Yes. It works for both shaft support (rotating) and pivot/hinge-style (oscillating) functions.
Q4: Is external lubrication necessary?
No. Under normal conditions, it’s maintenance-free due to internal oil content.
Q5: What temperature range can this bearing handle?
Typical operation is up to 150–200°C depending on system conditions and load.
Q6: What industries commonly use this bushing?
Used in electric tools, printers, robotics, pumps, and general industrial machinery.
The versatility of SINTERED BRONZE BUSHING 10X15X20 makes them ideal for numerous applications, including:
SINTERED BRONZE BUSHING 10X15X20 are engineered for demanding applications where traditional lubrication methods are impractical. They provide exceptional performance, durability, and cost-effectiveness, making them the preferred choice across various industries. Experience the reliability and efficiency of SINTERED BRONZE BUSHING 10X15X20, designed to meet your specific application requirements.
