Boccola Scorrevole in Premium-Qualità
| Produttore | DALON |
| Materiale | COMPOSITE MULTILAYER |
| Tipo | FLANGE BUSHING |
| Temperatura di Lavorazione ?/td> | From -200°C to + 280°C |
| Codice Prodotto | BMF1012189 |
| Densità (g/cm³) | 7.5 |
| Codice HS | 8483300090 |
| Durezza | >220 |
| Carico Statico (Mpa) | 250 |
| Velocità Massima (m/s) | 2.5 |
| Max PV (secco) | 1.8 |
| I.D.(d) | 10 |
| I.D. (d1) | |
| A.D. (D) | 12 |
| A.D. (D1) | |
| Lunghezza (L) | 1 |
| Diametro del Flangia (fd) | 18 |
| Spessore del Flangia (fl) | 9 |
| Tolleranza Generale | F7 r7 js13 |
| Peso(Ref.)/Gramm | 0.00 |
| Quantità Minima di Ordine | 40KGS |
DALON’s Sliding Flange Bushing 10×12×18×1×9 is a precision-formed, self-lubricating bronze bearing designed for compact assemblies that require both radial support and axial positioning. Featuring a flanged construction, this bushing combines easy installation with reliable alignment, making it ideal for applications with space constraints and light to moderate loads.
The dimension format follows DALON’s standardized spec sequence:
ID: 10 mm
OD: 12 mm
Flange OD: 18 mm
Flange Thickness: 1 mm
Total Length: 9 mm
Manufactured from high-density sintered bronze or bronze alloy, the bushing offers excellent wear resistance, thermal stability, and dry-running performance. The flange ensures secure axial location without additional fasteners or retainers, making it suitable for press-fit or slip-fit housing assemblies.
Dimensions: 10×12×18×1×9 mm (ID × OD × Flange OD × Flange Thickness × Total Length)
Material: Bronze alloy (self-lubricating; graphite optional)
Operating Conditions:
Temp Range: –40°C to +250°C
Load: Up to 60 N/mm² dynamic
Speed: Suitable for moderate speeds
Installation: Easy press-fit into aluminum or steel housings
Design Type: Oilless sliding sleeve with axial flange retention
Servo motor pivots and linkages
Pneumatic and hydraulic control systems
Compact automation equipment
Linear actuator interfaces
Portable machinery and miniature gearboxes
Office and home appliance mechanisms
Tailored Engineering: Custom bushing size, flange style, and lubrication type available
Fast Lead Times:
Standard mold items: ~30 days
Custom bushing (with mold): 35–40 days
Material Versatility: Options include sintered bronze, graphite-impregnated types, or custom bronze alloys
ISO 9001:2015 Certified Production
Support for Prototyping to Mass Production
|
Question |
Answer |
|---|---|
|
Q1: What is this bushing used for? |
It provides a low-friction, durable support for rotating or sliding shafts in small mechanical systems. |
|
Q2: What does the flange do? |
The flange holds the bushing in place axially and simplifies installation without additional hardware. |
|
Q3: Can I use this without grease or oil? |
Yes. It’s designed for dry-running with self-lubricating properties. Optional graphite versions are available. |
|
Q4: What is the delivery time for custom bushings? |
Normally 35–40 days for new designs; existing mold parts can be delivered in ~30 days. |
|
Q5: What materials are available? |
Standard is bronze alloy; custom materials such as bronze + graphite or POM can be quoted upon request. |
|
Q6: What industries use these bushings? |
Used in robotics, automation, automotive interiors, HVAC actuators, and light-duty machinery. |
Le proprietà auto-lubrificanti della SLIDING FLANGE BUSHING 10X12X18X1X9 la rendono ideale per molte applicazioni, inclusa:
SLIDING FLANGE BUSHING 10X12X18X1X9 sono progettati per ambienti in cui la lubrificazione tradizionale è impraticabile o impossibile. Offrono prestazioni straordinarie, durabilità e risparmi economici e sono quindi la scelta preferita in vari settori. Esperienza la affidabilità e l'efficienza di SLIDING FLANGE BUSHING 10X12X18X1X9, progettati per rispondere alle esigenze specifiche delle sue applicazioni.
Il nostro team professionale è a disposizione per aiutarti con la tua richiesta per questo Flanged Sliding Bushing – 10×12×18×1×9 Bronze Sleeve Bearing.
